EKS 414s

Jungheinrich EKS 414s

The Jungheinrich EKS 414s is an electric order picker renowned for its efficiency and precision in warehouse operations. With a nominal load capacity of 1.36 tons and a substantial lifting height of 5 meters, it caters to a variety of picking tasks. Its design emphasizes manoeuvrability with a compact wheelbase of 1.69 meters and a tight turning radius of 1.845 meters, which is ideal for navigating through the narrow aisles of a warehouse environment. It began production in 2021, featuring advanced traction and hoist motors that provide responsive control at a consistent travel speed, irrespective of the load. The EKS 414s is equipped with a 48V battery, ensuring consistent performance during intensive picking cycles.

Specifications

Load Capacity1.36 t
Lift Height5 m
Turning Radius1.8 m
Weight3.4 t
Dimensions3275x1000x2370 mm
Max Speed12 km/h

Powertrain

Power SourceElectric
Voltage48 V
Battery Weight917 kg
Lift Motor Power12 kW
Drive Motor Power6.5 kW
