Kramer 5009
The Kramer 5009, produced from 2015 to 2019, is a telehandler designed for heavy-duty lifting and material handling. With a robust load capacity of 5.5 tonnes at the centre of gravity and a significant horizontal reach of 4.79 m, it shines in its ability to handle large loads at height and distance. Its powerful Deutz TCD4.1 L4 engine can generate 115 kW of power, which, combined with its transmission type HY, allows for a smooth operation. The 5009's spacious transport dimensions and standard tyres provide stability and maneuverability while its emission level 3b compliance shows a consideration for environmental impact. With lift heights reaching over 8 m and the capability to travel at speeds up to 20 km/h, this model is a reliable choice for a variety of applications.
Specifications
Load Capacity | 5.5 t |
Lift Height | 8.5 m |
Weight | 10.6 t |
Dimensions | 5690x2500x2460 mm |
Max Speed | 20 km/h |
Powertrain
Power Source | Diesel |
Engine Power | 115 kW |
Engine Displacement | 4.1 l |
Emission Level | 3b |
